Friday, February 19, 2010

Saturday, February 13, 2010

rot.

Found this buried in the dirt in the crawlspace after the living room floor came up.  Think the DMV still has records on this one?
I pulled up the old oak flooring in the living room.  These two perpendicular layers of pine flooring were underneath.  The upper layer was fine but the bottom layer had some serious decay.  Looks like it rotted and someone long ago just covered it up rather than removing it.   I still don't know why  it had water damage - maybe a leaky roof at some point?
These boards in the middle were so rotten that they pulled up easily by hand.
Then I discovered some major rot in framing of the enclosed porch.  Now I know why the left side of the window was sinking.   The floor joist on the left just fell over when I pulled up the last strip of flooring.
The last layer coming up... Before I replace the subfloor I'll put diagonal bracing between the floor joists to add rigidity since they're so widely spaced and add a single pier in front of the fireplace to carry the weight of the future woodstove.   While I'm at it I'll clean all the old bones and trash out of the crawlspace and put down a vapor barrier.  And of course I'll have to rebuild the rotten framing under the window.
gone.

Sunday, February 7, 2010

misc. images

The seldom seen east side of the house...
The vertical lines in the siding indicate where an addition was put on (left side) and where a porch was walled in (right).  At one time there were boards, just like the ones on the corners, that covered those gaps.  They were likely removed when the asbestos siding was installed.
the more familiar view...
Under the front porch, showing the sandstone piers and brick infill as well as the 6x6 beams that support wall studs and floor joists.
The original tongue and groove pine floor.  Notice how worn it is in front of the fireplace.  Several boards are worn all the way through the upper rail of their groove, exposing the tongue of the adjacent board.   I spend quite a bit of time squatting in this spot as well...warming my frozen hands by the fire.   The floor tells me that this has been a popular spot for a long time.
house cross-sections!   shows 6x6 foundation beam, floor joist (parallel to and just behind the beam), wall stud, subfloor (original finish floor).
